Power Protection Controllers



Dayliff power controllers are quality products used in various applications. This includes monitoring the incoming power supply and when outside pre-set limits disconnect the equipment, reconnecting on return of normal power after a start-up delay to protect against damaging power-back surges. The controllers are fitted with LED lights indicating the power status and installation couldn't be simpler. All controllers offer complete and reliable protection against the damage caused by fluctuating power and are essential accessories for all environments where there is a risk of inconsistent power supply.


AUTOMATIC VOLTAGESWITCHER (AVS 13&15)
Max Load: 13A/15A Single Phase
Reconnection Time: User-adjustable up to 3mins
Protection: High Voltage, Low Voltage, Power Back Surges, Spikes/Surges, Lightning
Applications: All electrical and electronic appliances, 15A particularly suitable for AC.
Physical Data: Weight 500gm, Dimensions 230x134x54mm


AUTOMATIC VOLTAGESWITCHER (AVS 30)
Max Load: 30A, Single Phase
Reconnection Time: User-adjustable up to 10mins
Protection: High Voltage, Low Voltage, Power Back Surges, Spikes/Surges, Lightning
Applications: All electrical and electronic equipment, complete office and home circuits. The direct wire connected.
Physical Data: Weight 600gm, Dimensions 230x134x54mm


AUTOMATIC VOLTAGESWITCHER (AVS 3P)

Max Load: 9A relay contact wired through control circuits or contactors for three-phase loads of any size.
Reconnection Time: User-adjustable up to 10mins.
Protection: High Voltage (user adjustable), Low Voltage (user adjustable), Power Back Surges, Spikes/Surges, Lightning, Single Phasing.
Applications: All electrical devices.
Physical Data: Wt 600gms, Dimensions 205x135x54mm


SOLLATEK HI VOLT GUARD
Max Load: 5 Amps, Single Phase
Reconnection Time: 30secs
Protection: Overvoltage, Spikes/Surges, Power Back Surges, Lightning
Applications: TV, Hi-fi, Video, PABX, Computers
Physical Data: Weight 250gm, Dimensions 250x130x95mm


SOLLATEK FRIDGE GUARD
Max Load: 5A, Single Phase
Reconnection Time: 90secs
Protection: Under voltage, Spikes/Surges, Power Back Surges, Lightning
Applications: Fridges, Freezers and Compressors
Physical Data: Weight 250gm, Dimensions 250x150x95mm


SOLLATEK LIGHTNING GUARD
Max Load: 5A Single Phase
Reconnection Time: 30secs
Protection: High Voltage, Spikes/Surges, Power Back Surges, Lightning, Telecom Surges. Prevents Lightning, Mains Surges and Spikes entering the telephone circuits.
Applications: Modem, Fax, Telephone. An RJ11 phone socket is provided.
Physical Data: Weight 300gm, Dimensions 180x90x95mm
